Fuses
There are twelve fuses that protect the electric
components, located inside the front and rear fuse
boxes, and one on the solenoid  There is a
spare fuse in every box:
●
box (A): 7.5A, 15A, 25A;
●
box (B): 10A, 15A, 25A.
Refer to the table below to identify the circuits
protected by the various fuses and their ratings.
The front fuse box (A) is located under the rider seat
and can be reached by removing the inspection
cover. To expose the fuses,  the box protective
cover. Mounting position and ampere capacity are
marked on box cover.
The rear fuse box (B) and the ABS fuse box
(C, Fig 202) are located under the rider seat. To reach
rear and ABS fuse boxes, remove rider seat, see page
60. To expose the fuses, remove box protective
cover. Mounting position and ampere capacity are
marked on box cover.
A
1 2 3 4 5 6 7
Fig 200
B
1 2 3 4 5 6 7
Fig 201
268
