Ducati SCRAMBLER 2023 User Manual

no. Description Colour
10 DAVC Diagnosis
●
flashing: DTC/DWC enabled, but with degraded 
●
on: DTC disabled and/or not functioning due to a fault in the control unit.
Amber yellow (display)
11 Fog lights on, if any Amber yellow (display)
12 MIL
●
The warning light turns steady on in case of error in engine management.
Proceed slowly, avoid harsh acceleration and  take the vehicle
to a Ducati authorised service centre to eliminate the malfunction.
●
The warning light turns on flashing to warn about a critical emission-re‐
lated error that could damage the catalytic  If possible, have the
vehicle be taken to a Ducati authorised service centre and the malfunc‐
tion eliminated and at any rate proceed slowly, avoid harsh acceleration
and 
Amber yellow (display)
13 Generic error Amber yellow (display)
14 Side stand down
Note
When the side stand is extended, the fuel indicator will not update.
When the side stand is in the rest (horizontal) position, the first update of the
fuel indicator will occur only  a few seconds.
Red (display)
15 High beam on Blue (display)
16 DRL – daytime running light on, set in “Auto” mode (see page 212) Green (display)
105

Ducati SCRAMBLER 2023 Specifications

General

Displacement	803 cc
Max Power	73 hp (54 kW) @ 8, 250 rpm
Fuel Injection	Electronic fuel injection, 50 mm throttle body
Transmission	6-speed
Front Suspension	Kayaba 41 mm upside-down fork
Rear Suspension	Kayaba rear shock, pre-load adjustable
Frame	Tubular steel Trellis frame
Front Tire	110/80 R18
Rear Tire	180/55 R17
Engine Type	L-Twin, Desmodromic distribution, air-cooled
Front Brake	330 mm disc, radial 4-piston caliper
Rear Brake	245 mm disc, 1-piston floating caliper
Dry Weight	170 kg (375 lbs)
Fuel Tank Capacity	13.5 l (3.6 US gal)
