Ducati SCRAMBLER 2023 User Manual


If the rear sprocket needs replacing, contact a
Ducati Dealer or authorised Service Centre.
If improperly replaced, this component could
seriously endanger your safety, as well as the
passenger one, and cause irreparable damage to
your motorcycle.
Frame
Aluminium monocoque.
Steering head angle: 27.6 °.
Trail: 122 mm (4.8 in).
Steering angle: 43 ° LH side / 43 ° RH side.
Plastic front subframe.
Rear subframe bolted to steel trellis.
Wheels
Front
Tangential spoke rim, tubeless.
Size: 2.15 " x 21 ".
Rear
Tangential spoke rim, tubeless.
Size: 4.5 " x 18 ".
Tyres
Note
Thanks to Pirelli, a tyre dedicated to this
motorcycle has been developed, with exclusive
construction features that enhance its
characteristics and guarantee the best 
Front
“Tubeless", radial tyre.
Make and type: Pirelli Scorpion Rally STR.
Size: 90/90 - 21 M/C 54V M+S TL (A).
Rear
“Tubeless", radial tyre.
Make and type: Pirelli Scorpion Rally STR.
Size: 150/70 R18 M/C 70V M+S TL.
TYRE PRESSURE
Front tyre pressure
2.0 bar (29.0 PSI) (on road, rider only);
2.2 bar (31.9 PSI) (on road, rider and passenger);
1.8 bar (26.1 PSI)  rider only);
2.0 bar (29.0 PSI)  rider and passenger).
Rear tyre pressure
304

Ducati SCRAMBLER 2023 Specifications

General

Displacement	803 cc
Max Power	73 hp (54 kW) @ 8, 250 rpm
Fuel Injection	Electronic fuel injection, 50 mm throttle body
Transmission	6-speed
Front Suspension	Kayaba 41 mm upside-down fork
Rear Suspension	Kayaba rear shock, pre-load adjustable
Frame	Tubular steel Trellis frame
Front Tire	110/80 R18
Rear Tire	180/55 R17
Engine Type	L-Twin, Desmodromic distribution, air-cooled
Front Brake	330 mm disc, radial 4-piston caliper
Rear Brake	245 mm disc, 1-piston floating caliper
Dry Weight	170 kg (375 lbs)
Fuel Tank Capacity	13.5 l (3.6 US gal)
