Ducati SCRAMBLER 2023 User Manual

Trip master
This function is only available in the “Rally” screen
(see page 107).
The trip master is displayed in the centre of the
"Rally" screen: it calculates and displays the 
distance (in km or miles) travelled by the motorbike
and can be set to incremental or  mode, it
can also be temporarily stopped and reset to zero.
You must have selected the trip master (A), if
necessary move the selection from the Interactive
Menu by holding down  (2) or from the Info
display by holding down  (1).
The trip master accuracy level can be set via the "Trip
master precision" function in the  menu"
(see page 251).
Air
22
°C
90
°C
Range km429
Total km2600
10:34
am
A
429
km
0
km
Off
km/h
0
Gear
RALLY
DWC 3 DTC 5 ABS 3 EBC 2
N
Chrono
Setting menu
1
3
2
A
B
Fig 74
131

Ducati SCRAMBLER 2023 Specifications

General

Displacement	803 cc
Max Power	73 hp (54 kW) @ 8, 250 rpm
Fuel Injection	Electronic fuel injection, 50 mm throttle body
Transmission	6-speed
Front Suspension	Kayaba 41 mm upside-down fork
Rear Suspension	Kayaba rear shock, pre-load adjustable
Frame	Tubular steel Trellis frame
Front Tire	110/80 R18
Rear Tire	180/55 R17
Engine Type	L-Twin, Desmodromic distribution, air-cooled
Front Brake	330 mm disc, radial 4-piston caliper
Rear Brake	245 mm disc, 1-piston floating caliper
Dry Weight	170 kg (375 lbs)
Fuel Tank Capacity	13.5 l (3.6 US gal)
