Ducati SCRAMBLER 2023 User Manual

Engine
 11 °, twin cylinder, "L" type,
desmodromic timing system, 4 valves per cylinder,
liquid cooling.
Bore: 94 mm (3.70 in).
Stroke: 67.5 mm (2.66 in).
Total displacement: 937 cu. cm (57.18 cu in).
Compression ratio: 13.3:1.
Maximum power at  (EU) Regulation no.
134/2014, Annex X, kW/HP:
81 kW / 110 HP at 9250 rpm.
Maximum torque at  (EU) Regulation no.
134/2014 Annex X:
92 Nm / 9.4 kgm at 6500 rpm.
Max. rotation speed: 10,200 rpm.
Lubrication: lobe-type oil pump with built-in by-pass
valve and oil cooler.
Note
The indicated power/torque values have been
measured with a static test bench according to type-
approval standards and match with the data
detected during type-approval process; they are
indicated in the vehicle registration document.

Maximum speed in any gear should be reached only
 a correct running-in period with the motorcycle
properly serviced at the recommended intervals.

Failure to follow these instructions releases
Ducati Motor Holding S.p.A. from any liability
whatsoever for any engine damage or  engine
life.
Spark plugs
Make: NGK.
Type: MAR9A-J.
Fuel system
Electronic injection.
MIKUNI  body with full Ride by wire system,
diameter: 53 mm (2.09 in), round cross-section.
Injectors per cylinder: 1.
301

Ducati SCRAMBLER 2023 Specifications

General

Displacement	803 cc
Max Power	73 hp (54 kW) @ 8, 250 rpm
Fuel Injection	Electronic fuel injection, 50 mm throttle body
Transmission	6-speed
Front Suspension	Kayaba 41 mm upside-down fork
Rear Suspension	Kayaba rear shock, pre-load adjustable
Frame	Tubular steel Trellis frame
Front Tire	110/80 R18
Rear Tire	180/55 R17
Engine Type	L-Twin, Desmodromic distribution, air-cooled
Front Brake	330 mm disc, radial 4-piston caliper
Rear Brake	245 mm disc, 1-piston floating caliper
Dry Weight	170 kg (375 lbs)
Fuel Tank Capacity	13.5 l (3.6 US gal)
