Ducati SCRAMBLER 2023 User Manual

Checking brake and clutch fluid level
Check the brake fluid level with the vehicle in a
 position,  by centre stand (where
available), and on a flat 
Front brake fluid reservoir (1)
Front brake fluid level must be above the sight glass
(A).
Rear brake fluid reservoir (2)
The fluid level must not be under the "MIN"notch
marked on reservoir (2) side.
Clutch fluid reservoir (3)
To check clutch fluid level on reservoir (3), contact a
Ducati Dealer or Authorised Service Centre.
If level drops below the limit, air might get into the
circuits and  the operation of the system
involved.
Brake and clutch fluid must be topped up and
changed at the intervals specified in the scheduled
maintenance  under “Scheduled maintenance”;
please contact a Ducati Dealer or Authorised Service
Centre.
MAX
MIN
MAX
MIN
1
A
2
Fig 172
3
Fig 173
264

Ducati SCRAMBLER 2023 Specifications

General

Displacement	803 cc
Max Power	73 hp (54 kW) @ 8, 250 rpm
Fuel Injection	Electronic fuel injection, 50 mm throttle body
Transmission	6-speed
Front Suspension	Kayaba 41 mm upside-down fork
Rear Suspension	Kayaba rear shock, pre-load adjustable
Frame	Tubular steel Trellis frame
Front Tire	110/80 R18
Rear Tire	180/55 R17
Engine Type	L-Twin, Desmodromic distribution, air-cooled
Front Brake	330 mm disc, radial 4-piston caliper
Rear Brake	245 mm disc, 1-piston floating caliper
Dry Weight	170 kg (375 lbs)
Fuel Tank Capacity	13.5 l (3.6 US gal)
