Ducati SCRAMBLER 2023 User Manual

Error warnings
The instrument panel manages error warnings in
order to allow the rider to identify any abnormal
motorcycle behaviour in real time.
If there is an error, the instrument panel shows the
indication in red on the main screen, in large format
(A) for the first 10 seconds and then in small format
(B).
The warning then remains active until the error is
resolved.
When several errors are active, they are displayed in
a sequence, one every 5 seconds.
Traction control error!
Activation of this error indicates that it is necessary
to go to a Ducati Authorised Service Centre as the
vehicle Traction Control is in error: (C) in the "Full"
screen, (D) in the "Rally" screen and "Turn by turn" (if
available, see page 138).
To change the display mode of the current Riding
Mode, see page 200.
Air
22
°C
90
°C
Range km450
Total km2600
rpm X1000
1
2
3
4
5
6
7
10
11
4
0
km/h
Gear
N
SPORT
DWC 3 DTC 5 ABS 3 EBC 2
10:34
am
Chrono
Setting menu
A
Air
22
°C
90
°C
Range km450
Total km2600
rpm X1000
1
2
3
4
5
6
7
10
11
4
0
km/h
Gear
N
SPORT
DWC 3 DTC 5 ABS 3 EBC 2
10:34
am
Chrono
Setting menu
A
km/h
0
Gear
N
Traction control
error!
km/h
Traction control
error!
N
Gear
ABS
error!
Traction control
error!
ABS
error!
Traction control
error!
0
C D
A
B
Fig 169
261

Ducati SCRAMBLER 2023 Specifications

General

Displacement	803 cc
Max Power	73 hp (54 kW) @ 8, 250 rpm
Fuel Injection	Electronic fuel injection, 50 mm throttle body
Transmission	6-speed
Front Suspension	Kayaba 41 mm upside-down fork
Rear Suspension	Kayaba rear shock, pre-load adjustable
Frame	Tubular steel Trellis frame
Front Tire	110/80 R18
Rear Tire	180/55 R17
Engine Type	L-Twin, Desmodromic distribution, air-cooled
Front Brake	330 mm disc, radial 4-piston caliper
Rear Brake	245 mm disc, 1-piston floating caliper
Dry Weight	170 kg (375 lbs)
Fuel Tank Capacity	13.5 l (3.6 US gal)
