Ducati SCRAMBLER 2023 User Manual

Light control
Low / High beam
By means of  (1) it is possible to switch from
low beam to high beam and vice versa:
●
position (A) for high beam
●
position (B) for low beam
For high-beam flasher, press the  (1) in
position (C).
If engine is not   turning the key to on, it
is  possible to switch on the lights or
flash.
If within 60 seconds from the manual switching on of
the low or high beam the engine is not  the
lights are turned 
To preserve the motorcycle  the headlight is
automatically switched  when  the engine
and it is then switched on again when the engine has

DRL in "Auto" mode – only for version with
DRL
If DRL have been set in "Auto" mode (see page 212),
the instrument panel automatically manages the
DRL based on the detected ambient light:
C
1
2
1
B
C
A
B
Fig 38
70

Ducati SCRAMBLER 2023 Specifications

General

Displacement	803 cc
Max Power	73 hp (54 kW) @ 8, 250 rpm
Fuel Injection	Electronic fuel injection, 50 mm throttle body
Transmission	6-speed
Front Suspension	Kayaba 41 mm upside-down fork
Rear Suspension	Kayaba rear shock, pre-load adjustable
Frame	Tubular steel Trellis frame
Front Tire	110/80 R18
Rear Tire	180/55 R17
Engine Type	L-Twin, Desmodromic distribution, air-cooled
Front Brake	330 mm disc, radial 4-piston caliper
Rear Brake	245 mm disc, 1-piston floating caliper
Dry Weight	170 kg (375 lbs)
Fuel Tank Capacity	13.5 l (3.6 US gal)
