Ducati SCRAMBLER 2023 User Manual

Charging the 
Preparation
We recommend recharging the lithium  by
connecting the suitable  charger directly to
the positive and negative terminals of the 
using the cable with clips.
To gain access to  and charge it, remove rider
seat as indicated in chapter "Seat lock".
Press tab (A) of retainer (1) downwards, releasing it
from hook (B) and  elastic band (2).
Slide out protective gaiter (3) and loosen terminal
retaining screws (4):
●
negative and ground cables (5);
●
positive and ABS positive cables (6).
Slide out the  (7) from top.
A
B
2
1
Fig 176
4
7
5
6
3
Fig 177
267

Ducati SCRAMBLER 2023 Specifications

General

Displacement	803 cc
Max Power	73 hp (54 kW) @ 8, 250 rpm
Fuel Injection	Electronic fuel injection, 50 mm throttle body
Transmission	6-speed
Front Suspension	Kayaba 41 mm upside-down fork
Rear Suspension	Kayaba rear shock, pre-load adjustable
Frame	Tubular steel Trellis frame
Front Tire	110/80 R18
Rear Tire	180/55 R17
Engine Type	L-Twin, Desmodromic distribution, air-cooled
Front Brake	330 mm disc, radial 4-piston caliper
Rear Brake	245 mm disc, 1-piston floating caliper
Dry Weight	170 kg (375 lbs)
Fuel Tank Capacity	13.5 l (3.6 US gal)
