Ducati SCRAMBLER 2023 User Manual

Restoring motorcycle operation via
the PIN code
In case of key acknowledgement system or key
malfunction, the instrument panel allows the user to
enter his/her own PIN code to temporarily restore
motorcycle operation.
If the PIN code was activated via the “ PIN Code”
function in the  menu” (see page 158), the
instrument panel displays “PIN Code” with four
spaces for the four digits of the PIN code.
Entering the code:
●
The values displayed above the digit indicate
that the number can be changed from 0 to 9
using  (1) and (2).
●
Press ENTER (3) to confirm and move on to the
following digit.
●
Repeat the procedure until entering all 4 digits.
Once the  digit is set, press ENTER (3) and the
instrument panel behaviour will be as follows:
●
if there is a problem during the PIN check, the
instrument panel displays “Time out” for 2
seconds and then passes to the main screen;
●
if the PIN code is not correct, the instrument
panel displays “Wrong” for 2 seconds and then
0 0 0 0
1
2
PIN code:
2
2
2
2
2
1
3
2
Fig 42
77

Ducati SCRAMBLER 2023 Specifications

General

Displacement	803 cc
Max Power	73 hp (54 kW) @ 8, 250 rpm
Fuel Injection	Electronic fuel injection, 50 mm throttle body
Transmission	6-speed
Front Suspension	Kayaba 41 mm upside-down fork
Rear Suspension	Kayaba rear shock, pre-load adjustable
Frame	Tubular steel Trellis frame
Front Tire	110/80 R18
Rear Tire	180/55 R17
Engine Type	L-Twin, Desmodromic distribution, air-cooled
Front Brake	330 mm disc, radial 4-piston caliper
Rear Brake	245 mm disc, 1-piston floating caliper
Dry Weight	170 kg (375 lbs)
Fuel Tank Capacity	13.5 l (3.6 US gal)
