Ducati SCRAMBLER 2023 User Manual

Rear brake calliper
Brake calliper make: Brembo, 2-piston floating
calliper with Bosch Cornering ABS.
Number of pistons: 2.
Piston diameter: 11 mm (0.43 in).

The brake fluid used in the brake system is
corrosive.
In the event of accidental contact with eyes or skin,
wash the  area with abundant running water.
Transmission
Hydraulically-controlled slipper/self-servo Wet
multiplate clutch.
Drive is  from engine to gearbox primary
 via spur gears, 1.85:1 ratio.
Front chain sprocket/clutch gearwheel ratio: 33/61.
6-speed gearbox with constant mesh gears, gear
change pedal on  side of motorcycle equipped
with Ducati Quick  /DQS) up/down EVO.
Gearbox output sprocket/rear chain sprocket ratio:
15/49.
Total gear ratios:
1
st
gear 14/38.
2
nd
gear 17/31.
3
rd
gear 20/28.
4
th
gear 22/26.
5
th
gear 23/24.
6
th
gear 24/23.
Drive chain from gearbox to rear wheel.
Make: Regina.
Type: 525/137ZRDB.
Links: 114.
No. of links (China version): 112.

The above gear ratios are the homologated
ones and under no circumstances must they be
modified.
However, if you wish to tune up your motorcycle for
competitions or special tracks, Ducati Motor Holding
S.p.A. will be pleased to provide information about
the special ratios available. Contact a Ducati Dealer
or Authorised Service Centre.
303

Ducati SCRAMBLER 2023 Specifications

General

Displacement	803 cc
Max Power	73 hp (54 kW) @ 8, 250 rpm
Fuel Injection	Electronic fuel injection, 50 mm throttle body
Transmission	6-speed
Front Suspension	Kayaba 41 mm upside-down fork
Rear Suspension	Kayaba rear shock, pre-load adjustable
Frame	Tubular steel Trellis frame
Front Tire	110/80 R18
Rear Tire	180/55 R17
Engine Type	L-Twin, Desmodromic distribution, air-cooled
Front Brake	330 mm disc, radial 4-piston caliper
Rear Brake	245 mm disc, 1-piston floating caliper
Dry Weight	170 kg (375 lbs)
Fuel Tank Capacity	13.5 l (3.6 US gal)
