Ducati SCRAMBLER 2023 User Manual

Engine rpm indication
The engine rpm are displayed as follows:
●
using a rev counter with a grey wake (A) in the
“Full” display mode (see page 107);
●
using a rev counter featuring a wake (B) in the
“Rally” display mode (see page 107) or in the
“Turn by turn” screen if available (see page 138).
During the first 1000 km (600 mi) of the odometer
(vehicle running-in period), or up to the first service,
a  engine rpm limiter is set to 6000 rpm
regardless of the engine temperature and is
indicated when the wake becomes amber yellow.
 the running-in period or  the first
inspection, the  limiter indicates and advises
the rider to ride at lower revs when the engine is cold.
The  limiter threshold changes according to
the engine temperature:
●
If the engine temperature is below 40 °C
(104 °F), the rev counter wake will turn amber
yellow  6000 rpm;
●
if the engine temperature is within 40 °C (104 °F)
and 60 °C (140 °F), the rev counter wake will turn
amber yellow  8000 rpm;
Air
22
°C
90
°C
Range km450
Total km2600
10:34
am
A
450
km
0
km
Off
km/h
120
Gear
RALLY
4
1 2 3 4 5 6 7 8 9 10 11
rpm
X1000
Chrono
Setting menu
Air
22
°C
90
°C
Range km450
Total km2600
rpm X1000
1
2
3
4
5
6
7
10
11
4
SPORT
10:34
am
Chrono
Setting menu
A
km/h
120
4
Gear
A B
Fig 66
117

Ducati SCRAMBLER 2023 Specifications

General

Displacement	803 cc
Max Power	73 hp (54 kW) @ 8, 250 rpm
Fuel Injection	Electronic fuel injection, 50 mm throttle body
Transmission	6-speed
Front Suspension	Kayaba 41 mm upside-down fork
Rear Suspension	Kayaba rear shock, pre-load adjustable
Frame	Tubular steel Trellis frame
Front Tire	110/80 R18
Rear Tire	180/55 R17
Engine Type	L-Twin, Desmodromic distribution, air-cooled
Front Brake	330 mm disc, radial 4-piston caliper
Rear Brake	245 mm disc, 1-piston floating caliper
Dry Weight	170 kg (375 lbs)
Fuel Tank Capacity	13.5 l (3.6 US gal)
