Ducati SCRAMBLER 2023 User Manual

Vehicle 
Before  the motorcycle using another
vehicle, follow the safety instructions below.
1) Remove all loose objects and accessories from
the vehicle;
2) Align the front wheel straight in the riding
direction and lock it properly to prevent any
movement;
3) Engage the first gear;
4) Use the anchoring straps and apply them to
strong components (e.g. frame) and NOT to the
handlebar (or handlebars, where present) or to
components that could break (e.g. handgrips,
rear-view mirrors, etc.);
5) The straps or ropes must NOT rub against any
painted motorcycle components;
6) The suspensions, if possible, must be in a
 compressed position so as to allow less
movement of the vehicle with respect to the
road  during 
Do NOT  the ropes to the handlebar.
Fig 195
291

Ducati SCRAMBLER 2023 Specifications

General

Displacement	803 cc
Max Power	73 hp (54 kW) @ 8, 250 rpm
Fuel Injection	Electronic fuel injection, 50 mm throttle body
Transmission	6-speed
Front Suspension	Kayaba 41 mm upside-down fork
Rear Suspension	Kayaba rear shock, pre-load adjustable
Frame	Tubular steel Trellis frame
Front Tire	110/80 R18
Rear Tire	180/55 R17
Engine Type	L-Twin, Desmodromic distribution, air-cooled
Front Brake	330 mm disc, radial 4-piston caliper
Rear Brake	245 mm disc, 1-piston floating caliper
Dry Weight	170 kg (375 lbs)
Fuel Tank Capacity	13.5 l (3.6 US gal)
