Ducati SCRAMBLER 2023 User Manual

Seat lock
By operating lock with key (1), you can remove the
rider seat in order to gain access to the tool kit,
 relays, fuses,  charge maintaining
connector, and 12 V charge socket.
Turn the key clockwise by 1/4 of a tun, until the seat
catch disengages with an audible click.
 rider seat (2) from the front side and slide it out
by releasing tab (A) from the back fastener (B) on
frame.
1
OPEN
Fig 17
2
2
A B
Fig 18
50

Ducati SCRAMBLER 2023 Specifications

General

Displacement	803 cc
Max Power	73 hp (54 kW) @ 8, 250 rpm
Fuel Injection	Electronic fuel injection, 50 mm throttle body
Transmission	6-speed
Front Suspension	Kayaba 41 mm upside-down fork
Rear Suspension	Kayaba rear shock, pre-load adjustable
Frame	Tubular steel Trellis frame
Front Tire	110/80 R18
Rear Tire	180/55 R17
Engine Type	L-Twin, Desmodromic distribution, air-cooled
Front Brake	330 mm disc, radial 4-piston caliper
Rear Brake	245 mm disc, 1-piston floating caliper
Dry Weight	170 kg (375 lbs)
Fuel Tank Capacity	13.5 l (3.6 US gal)
