displayed. The new Riding Mode is confirmed
and stored only when brakes are released and
then the main screen is displayed.
●
If both of the above conditions occur, the
message "Close  and release brakes" is
displayed. The new Riding Mode is confirmed
and stored only when both conditions are
satisfied and then the main screen is displayed.
If either of the conditions required to validate the
change of Riding Mode are not true within 5 seconds
from activation of one of the above-described
conditions, the procedure will be  the
instrument panel will go back to displaying the main
page and no  will be changed.

Ducati recommends changing the Riding Mode
when the motorcycle is stopped. If it is changed
while riding, be very careful (it is recommended to
change the Riding mode at a low speed).
116

Ducati SCRAMBLER 2023 Specifications

General

Displacement	803 cc
Max Power	73 hp (54 kW) @ 8, 250 rpm
Fuel Injection	Electronic fuel injection, 50 mm throttle body
Transmission	6-speed
Front Suspension	Kayaba 41 mm upside-down fork
Rear Suspension	Kayaba rear shock, pre-load adjustable
Frame	Tubular steel Trellis frame
Front Tire	110/80 R18
Rear Tire	180/55 R17
Engine Type	L-Twin, Desmodromic distribution, air-cooled
Front Brake	330 mm disc, radial 4-piston caliper
Rear Brake	245 mm disc, 1-piston floating caliper
Dry Weight	170 kg (375 lbs)
Fuel Tank Capacity	13.5 l (3.6 US gal)
