Ducati SCRAMBLER 2023 User Manual

Changing Riding Mode
Note
If the "Rally" screen is active, make sure that
the Trip master function is selected.
●
Press and hold the MODE/ENTER  (3) for
a long time.
●
The dedicated screen is displayed where, using
 (1) and (2), it is possible to scroll through
the available Riding Modes and display the
parameters with the relevant set values.
●
Press the MODE/ENTER  (3) to confirm.
Select "Exit" and press MODE/ENTER  (3) to
quit the screen without making any changes.
As soon as the new Riding Mode is confirmed, the
instrument panel checks the following conditions:
●
If speed is lower than or equal to 5 km/h (3 mph)
and  control is open, the message “Close
 is displayed; the new Riding Mode is
confirmed and stored only when  control
is closed and then the main screen is displayed.
●
If speed is lower than or equal to 5 km/h (3 mph),
 control is closed but brakes are
actuated, the message “Release brakes” is
Gear
N0
km/h
Exit
RALLY
ENDURO
SPORT
WET
Power
High
DWC
2
DTC
3
DQS
Off
ABS
1
EBC
1
W
W
W
W
W
ET
ET
ET
ET
ET
S
S
S
S
S
PO
PO
PO
PO
PO
RT
RT
RT
RT
RT
1
3
2
Fig 65
115

Ducati SCRAMBLER 2023 Specifications

General

Displacement	803 cc
Max Power	73 hp (54 kW) @ 8, 250 rpm
Fuel Injection	Electronic fuel injection, 50 mm throttle body
Transmission	6-speed
Front Suspension	Kayaba 41 mm upside-down fork
Rear Suspension	Kayaba rear shock, pre-load adjustable
Frame	Tubular steel Trellis frame
Front Tire	110/80 R18
Rear Tire	180/55 R17
Engine Type	L-Twin, Desmodromic distribution, air-cooled
Front Brake	330 mm disc, radial 4-piston caliper
Rear Brake	245 mm disc, 1-piston floating caliper
Dry Weight	170 kg (375 lbs)
Fuel Tank Capacity	13.5 l (3.6 US gal)
