Ducati SCRAMBLER 2023 User Manual

Connecting the  to the charger
Connect the  charger (C) positive (6a) and
negative (5a) leads to the  terminals: the red
one (8) to the positive terminal (+), the black one (9)
to the negative terminal (-).
Connect the plug of the  charger to the wall
outlet.
Do not use  chargers for lead  or any
other type of  maintainer/charger. Charge
the  ensuring the vehicle is in a room with a
temperature below 40° C (104° F).

Keep the  out of the reach of children.

Use only the Ducati-approved  charger
(C) for lithium  also as a maintainer. Do not
use the  charge maintainer kit  no.
69924601A (various countries) or  charge
maintainer kit no. 69924601AX (for Japan, China and
Australia only), as it is specific for lead 
5a6a
C
Fig 178
8 9
Fig 179
268

Ducati SCRAMBLER 2023 Specifications

General

Displacement	803 cc
Max Power	73 hp (54 kW) @ 8, 250 rpm
Fuel Injection	Electronic fuel injection, 50 mm throttle body
Transmission	6-speed
Front Suspension	Kayaba 41 mm upside-down fork
Rear Suspension	Kayaba rear shock, pre-load adjustable
Frame	Tubular steel Trellis frame
Front Tire	110/80 R18
Rear Tire	180/55 R17
Engine Type	L-Twin, Desmodromic distribution, air-cooled
Front Brake	330 mm disc, radial 4-piston caliper
Rear Brake	245 mm disc, 1-piston floating caliper
Dry Weight	170 kg (375 lbs)
Fuel Tank Capacity	13.5 l (3.6 US gal)
