if the instrument panel detects good light
conditions (day) the DRL are turned on and the
low beam is turned 
if the instrument panel detects poor light
conditions (night) the DRL are turned  and
the low beam is turned on.
When the DRL are set to “Auto” mode, the
corresponding warning light (16,Fig 60) will turn on.
By pressing  (2, Fig 38) DRL are turned  by
pressing again  (2, Fig 38) DRL turn on with
control strategy set to "Manual".
In this case, upon next Key-On, DRL will be again set
to "Auto" mode.

Using the DRL in "Auto" mode in case of poor
light conditions, especially in case of fog or clouds,
could impair safety. In this case Ducati recommends
to manually activate the low beam.
DRL in "Manual" mode – only for version with
DRL
If DRL have been set in "Manual" mode (see page
212), to turn  or on the DRL, use ( 2,Fig 38).
When the DRL are set to “Manual” mode, the
corresponding warning light (17,Fig 60) will turn on.

Using the DRL in poor light conditions (dark)
could compromise the riding visibility and dazzle
anyone coming on the opposite lane.

Using the DRL during the day improves
visibility compared to low beam.
Fog lights (if any)
To switch the fog lights 
if DRL are present, press and hold 
(2, Fig 38) for a long time;
if DRL are not present, press  (2, Fig 38).
When the fog lights are on, the corresponding
warning light (11, Fig 60)will turn on( Fig 60)
71

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Ducati SCRAMBLER 2023 and is the answer not in the manual?

Ducati SCRAMBLER 2023 Specifications

General IconGeneral
Displacement803 cc
Max Power73 hp (54 kW) @ 8, 250 rpm
Fuel InjectionElectronic fuel injection, 50 mm throttle body
Transmission6-speed
Front SuspensionKayaba 41 mm upside-down fork
Rear SuspensionKayaba rear shock, pre-load adjustable
FrameTubular steel Trellis frame
Front Tire110/80 R18
Rear Tire180/55 R17
Engine TypeL-Twin, Desmodromic distribution, air-cooled
Front Brake330 mm disc, radial 4-piston caliper
Rear Brake245 mm disc, 1-piston floating caliper
Dry Weight170 kg (375 lbs)
Fuel Tank Capacity13.5 l (3.6 US gal)
