Ducati SCRAMBLER 2023 User Manual

Set date (G)
The yellow colour indicates that the date must be
entered using the "Date and time" function in the
 menu" (page 225).
Key not acknowledged (H)
Yellow indicates that the  key was not
acknowledged.
Ice (I)
Yellow, it means that there might be ice on the road,
due to a low temperature. Warning is activated when
the instrument panel detects a temperature of 4°C
(39°F) or lower than that. Warning will be disabled as
soon as temperature rises up to 6 °C (43 °F).

This warning does not exclude the fact that
there may be some ice on the road also if
temperature is higher than 4 °C (39 °F). When the
temperature is low, it is recommended to always ride
with great care, especially on path sections not under
the sun and/or bridges.
Low fuel (J)
Yellow, it indicates that the fuel level is low. There is
no small version of the warning.
Note
When the motorbike is in low fuel condition, if
the main screen is set to “Full” mode and the fuel
indicator is set to "Level", the level will automatically
be displayed in remaining km or miles. When the low
fuel condition is over, the fuel indicator will return to
the previously set display.
H
I
G G
H
I
J
Date
Set
date
No
key
Ice
Low
fuel
Fig 168
260

Ducati SCRAMBLER 2023 Specifications

General

Displacement	803 cc
Max Power	73 hp (54 kW) @ 8, 250 rpm
Fuel Injection	Electronic fuel injection, 50 mm throttle body
Transmission	6-speed
Front Suspension	Kayaba 41 mm upside-down fork
Rear Suspension	Kayaba rear shock, pre-load adjustable
Frame	Tubular steel Trellis frame
Front Tire	110/80 R18
Rear Tire	180/55 R17
Engine Type	L-Twin, Desmodromic distribution, air-cooled
Front Brake	330 mm disc, radial 4-piston caliper
Rear Brake	245 mm disc, 1-piston floating caliper
Dry Weight	170 kg (375 lbs)
Fuel Tank Capacity	13.5 l (3.6 US gal)
