Ducati SCRAMBLER 2023 User Manual

Controls
Once the trip master has been activated, it is
possible to scroll through and select the following
controls by pressing the ENTER  (3) briefly, to
activate the selected control, long press the ENTER
 (3):
●
"On" displayed if the trip master is active (C).
●
pause displayed if the trip master counter is
running, or play displayed if the trip master
counter is paused (D).
●
reset to reset the counter (E).
●
incremental or  to change the
distance calculation mode (F).
Note
By briefly pressing  (1) and (2) you can
increase or decrease the counted distance at any
time (specific function for Roadbook navigation).
At any time, even with the trip master counter
running, it is possible to move the selection to the
Interactive Menu by long-pressing  (1) or to
the Info display by long-pressing  (2), in order
to access the other functions of the instrument
panel.
0
km
On
1.6
km
On
C
D E F
Fig 76
133

Ducati SCRAMBLER 2023 Specifications

General

Displacement	803 cc
Max Power	73 hp (54 kW) @ 8, 250 rpm
Fuel Injection	Electronic fuel injection, 50 mm throttle body
Transmission	6-speed
Front Suspension	Kayaba 41 mm upside-down fork
Rear Suspension	Kayaba rear shock, pre-load adjustable
Frame	Tubular steel Trellis frame
Front Tire	110/80 R18
Rear Tire	180/55 R17
Engine Type	L-Twin, Desmodromic distribution, air-cooled
Front Brake	330 mm disc, radial 4-piston caliper
Rear Brake	245 mm disc, 1-piston floating caliper
Dry Weight	170 kg (375 lbs)
Fuel Tank Capacity	13.5 l (3.6 US gal)
