Ducati SCRAMBLER 2023 User Manual

The levels from 1 to 3 and the bike with the 
 by the  highlighted, followed by the
reference indications, are displayed.
The  of the screen shows the level currently
set.
Use  (1) and (2) to scroll and select the desired
level. Press ENTER (3) to validate, then select "Back",
and press ENTER (3) again to exit.
Using the brakes correctly under adverse conditions
is the hardest – and yet the most critical - skill to
master for a rider. Braking is one of the most 
and dangerous moments when riding a two wheeled
motorcycle: the possibility of falling or having an
accident during this  moment is statistically
higher than any other moment. When one or both
wheels lock, the stabilising action of traction fails,
resulting in loss of control of the vehicle.
The Anti-Lock Brake System (ABS) has been
developed to enable riders to use the motorcycle
braking power to the fullest possible amount in
emergency braking or under poor pavement or
adverse weather conditions. ABS is an electro-
hydraulic device that controls the pressure in the
brake circuit when the control unit, by processing
N
Gear
OFF-ROAD ROAD
STABILITYPERFORMANCE
2
Riding mode Touring ABS
2
1
3
OFF-ROAD
ROA
D
Fig 105
171

Ducati SCRAMBLER 2023 Specifications

General

Displacement	803 cc
Max Power	73 hp (54 kW) @ 8, 250 rpm
Fuel Injection	Electronic fuel injection, 50 mm throttle body
Transmission	6-speed
Front Suspension	Kayaba 41 mm upside-down fork
Rear Suspension	Kayaba rear shock, pre-load adjustable
Frame	Tubular steel Trellis frame
Front Tire	110/80 R18
Rear Tire	180/55 R17
Engine Type	L-Twin, Desmodromic distribution, air-cooled
Front Brake	330 mm disc, radial 4-piston caliper
Rear Brake	245 mm disc, 1-piston floating caliper
Dry Weight	170 kg (375 lbs)
Fuel Tank Capacity	13.5 l (3.6 US gal)
