Ducati SCRAMBLER 2023 User Manual

“Level” and “Range” are displayed.
The currently set mode is shown at the  of the
screen.
Use  (1) and (2) to scroll and select the desired
mode. Press ENTER (3) to validate, then select
"Back", and press ENTER (3) again to exit.
Note
When the fuel level is set to remaining km or
miles, the Range item is not displayed in the Info
display list.
Note
When the motorbike is in low fuel condition, if
the main screen is set to “Full” mode and the fuel
indicator is set to "Level", the level will automatically
be displayed in remaining km or miles. When the low
fuel condition is over, the fuel indicator will return to
the previously set display.
Note
When the side stand is extended, the fuel
indicator will not update.
When the side stand is in the rest (horizontal)
position, the first update of the fuel indicator will
occur only  a few seconds.
Fuel indicator
Level
Level
Range
Back
N
Gear
Back
B
B
B
B
ac
ac
ac
ac
k
k
k
k
Fig 123
211

Ducati SCRAMBLER 2023 Specifications

General

Displacement	803 cc
Max Power	73 hp (54 kW) @ 8, 250 rpm
Fuel Injection	Electronic fuel injection, 50 mm throttle body
Transmission	6-speed
Front Suspension	Kayaba 41 mm upside-down fork
Rear Suspension	Kayaba rear shock, pre-load adjustable
Frame	Tubular steel Trellis frame
Front Tire	110/80 R18
Rear Tire	180/55 R17
Engine Type	L-Twin, Desmodromic distribution, air-cooled
Front Brake	330 mm disc, radial 4-piston caliper
Rear Brake	245 mm disc, 1-piston floating caliper
Dry Weight	170 kg (375 lbs)
Fuel Tank Capacity	13.5 l (3.6 US gal)
