Ducati SCRAMBLER 2023 User Manual

 the 
Position  (7) inside the special 
aiming it in the indicated direction.
Connect the  cables, always  from the
positive (+) one, as indicated:
1) positive (+) and ABS positive cables (6);
2) negative (-) and ground cables (5).
Tighten terminal screws (4) and position protective
gaiter (3).
Bring elastic band (2) back to its original position by
 retainer (1) inside hook (B).
Reposition rider seat as indicated in chapter “Seat
lock”.

The  gives  explosive gases; never
cause sparks or allow naked flames and 
near the  When charging the  ensure
that the working area is properly ventilated.
4
7
5
6
3
Fig 180
B
2
1
Fig 181
270

Ducati SCRAMBLER 2023 Specifications

General

Displacement	803 cc
Max Power	73 hp (54 kW) @ 8, 250 rpm
Fuel Injection	Electronic fuel injection, 50 mm throttle body
Transmission	6-speed
Front Suspension	Kayaba 41 mm upside-down fork
Rear Suspension	Kayaba rear shock, pre-load adjustable
Frame	Tubular steel Trellis frame
Front Tire	110/80 R18
Rear Tire	180/55 R17
Engine Type	L-Twin, Desmodromic distribution, air-cooled
Front Brake	330 mm disc, radial 4-piston caliper
Rear Brake	245 mm disc, 1-piston floating caliper
Dry Weight	170 kg (375 lbs)
Fuel Tank Capacity	13.5 l (3.6 US gal)
