The window (C) is shown listing the last 7 calls made,
received or missed. If a number or contact is present
several times among the last calls, this is displayed
only once.
Use  (1) and (2) to scroll through the calls in
the list. Press ENTER (3) to make a call to the number
or contact selected in the list.
Call in progress
When a call is in progress, a green window is shown
with the name or number of the contact as well as
the item “End call” (D). To end the call, press the
ENTER  (3).
During the call, the solid arrow at the top (E)
indicates that, by holding down the  (1), you
can exit the call display to access other menus on the
main screen. The blue phone icon (F) is also activated
to indicate that the call is in progress.
To return to the call in progress window (D), select
"Phone” (B, Fig 6) from the Interactive Menu, and
press ENTER (3).
Note
The music player will be paused during a call.
10:34
am
Mario Rossi
Jeff Walker
10:34
am
Mario Rossi
End call
C
D
E
F
Fig 7
30

Ducati SCRAMBLER 2023 Specifications

General

Displacement	803 cc
Max Power	73 hp (54 kW) @ 8, 250 rpm
Fuel Injection	Electronic fuel injection, 50 mm throttle body
Transmission	6-speed
Front Suspension	Kayaba 41 mm upside-down fork
Rear Suspension	Kayaba rear shock, pre-load adjustable
Frame	Tubular steel Trellis frame
Front Tire	110/80 R18
Rear Tire	180/55 R17
Engine Type	L-Twin, Desmodromic distribution, air-cooled
Front Brake	330 mm disc, radial 4-piston caliper
Rear Brake	245 mm disc, 1-piston floating caliper
Dry Weight	170 kg (375 lbs)
Fuel Tank Capacity	13.5 l (3.6 US gal)
