Ducati SCRAMBLER 2023 User Manual

The player window (C) will be displayed where the
controls of the music player and the track currently
playing are shown. If the track is playing when the
function is entered, the player window is displayed
with the pause command active (D).
●
By briefly pressing  (1) and (2) you can
increase and decrease the volume respectively;
●
by briefly pressing the ENTER  (3) it is
possible to scroll and select the following
controls, to activate the selected control press
the ENTER  (3) for a long time:
●
previous track
●
play or pause
●
stop
●
next track
During playback of a track, the solid arrow at the top
(E) indicates that, by holding down the  (1),
you can exit the music player display to access other
menus on the main screen, while keeping the track
playing.
When ENTER  (3) is pressed with the stop
control
selected, the music player window is
closed and the current track is stopped.
10:34
am
Track 01 - spo...
10:34
am
Track 01 - spo...
C
D
C
D
E
Fig 10
34

Ducati SCRAMBLER 2023 Specifications

General

Displacement	803 cc
Max Power	73 hp (54 kW) @ 8, 250 rpm
Fuel Injection	Electronic fuel injection, 50 mm throttle body
Transmission	6-speed
Front Suspension	Kayaba 41 mm upside-down fork
Rear Suspension	Kayaba rear shock, pre-load adjustable
Frame	Tubular steel Trellis frame
Front Tire	110/80 R18
Rear Tire	180/55 R17
Engine Type	L-Twin, Desmodromic distribution, air-cooled
Front Brake	330 mm disc, radial 4-piston caliper
Rear Brake	245 mm disc, 1-piston floating caliper
Dry Weight	170 kg (375 lbs)
Fuel Tank Capacity	13.5 l (3.6 US gal)
