Ducati SCRAMBLER 2023 User Manual

Do not park on  or pebbled ground or on asphalt
melt by the sun heat and similar or the motorcycle
may fall over. When parking downhill, always
position the motorcycle with the rear wheel facing
downhill.
To pull down the side stand, hold the motorcycle
handlebar with both hands and push down on the
side stand (1) with your foot until it is fully extended.
Tilt the motorcycle until the side stand is resting on
the ground.
To move the side stand to its rest position (horizontal
position), lean the motorcycle to the right while
 the thrust arm (1) with your foot.
To ensure trouble-free operation of the side stand
joint, thoroughly clean it and then use SHELL
Alvania R3 grease to lubricate all friction points.

Do not sit on the motorcycle when it is
 on the side stand.
Note
Check for proper operation of the stand
mechanism (two springs, one into the other) and the
safety sensor (2) at regular intervals.
Note
It is possible to  the engine with stand
unfolded and gearbox in neutral.
1
2
Fig 27
57

Ducati SCRAMBLER 2023 Specifications

General

Displacement	803 cc
Max Power	73 hp (54 kW) @ 8, 250 rpm
Fuel Injection	Electronic fuel injection, 50 mm throttle body
Transmission	6-speed
Front Suspension	Kayaba 41 mm upside-down fork
Rear Suspension	Kayaba rear shock, pre-load adjustable
Frame	Tubular steel Trellis frame
Front Tire	110/80 R18
Rear Tire	180/55 R17
Engine Type	L-Twin, Desmodromic distribution, air-cooled
Front Brake	330 mm disc, radial 4-piston caliper
Rear Brake	245 mm disc, 1-piston floating caliper
Dry Weight	170 kg (375 lbs)
Fuel Tank Capacity	13.5 l (3.6 US gal)
