51
Dukane Manual Part No. 403–566–01
Section 5 – Rear Connectors
Jumper Block Options
The DPC II Plus may be customized to your spe-
cific requirements by means of internal jumpers lo-
cated on the main printed circuit board. Below is a
list of the jumper blocks, their default factory set-
tings and their alternate positions. Figures 5–11 and
5–12 on the following pages show the location of
the jumper blocks in more detail. The factory de-
fault setting is indicated by a diamond
◊
next to the
description in Figure 5–12.
Status Driver Normal State Selection
Jumper Block – SH701 (Pin 4 output on DB-25)
JU701 - Normally OFF (Factory Default)
JU702 - Normally ON
Status Driver Selection
Jumper Block – SH702 (Pin 4 output on DB-25)
JU703 - Ultrasound Active Status
JU704 - Overload Fault (Factory Default)
JU705 - Over temperature Fault
JU706 - System Fault
JU707 - Any Fault
Automation Cycle Stop or End Of Weld Selection
Jumper Block – SH704
JU713 - Normally OFF (Factory Default) – Use depends upon custom automation configuration
JU714 - Normally ON
JU715 - Automation Stop Fault – Move jumper to this position to use Auto Stop (Figure 7–13)
JU716 - Automation End of Weld (Factory Default)
Switch Debounce Filter Time Delay Selection
Jumper Block – SH705
JU717 - No Time Delay (used for electronic switches)
JU718 - 1 msec
JU719 - 10 msec (Factory Default)
JU720 - 22 msec
Timer Board Enable/Bypass
Jumper Block – SH706
JU723 - Timer Board Enable (normally selected for a DPC II Plus)
JU722 - Timer Board Bypass (Factory Default – used for standard DPC II)
