Dukane Manual Part No. 403–566–01
DPC
™
II Plus and EZ Welder System – User’s Manual
Interpreting the DPC II Plus Model Number
2200-LN4-PE-L2
Generator Controller Level
FREQUENCY
2 = 20 kHz
3 = 30 kHz
4 = 40 kHz
5 = 50 kHz
7 = 70 kHz
POWER RATING
015 = 150 w
035 = 350 w
050 = 500 w
070 = 700 w
100 = 1000 w
120 = 1200 w
170 = 1700 w
220 = 2200 w
INPUT POWER
MODULE
L = Low
power
module
H = High
power
module
N = Non-power
Factor
F = Power Factor
Corrected
TRANSDUCERS
2 = 2 ceramics
4 = 4 ceramics
P = Press Control Board
T = Time Only
E = Time & Energy
L2 = level 2
010 = 100 w
Figure 15–2 Interpeting the DPC II Plus Model Number
NOTE
Figure 15-2 is designed to help you determine
which options your DPC II Plus has. It is not
meant to suggest that all combinations of
these options are possible.
