Dukane Manual Part No. 403–566–01
Section 5 – Rear Connectors
Rear Panel Layout
All of the connectors contained on the DPC II
Plus and the optional modules are shown below
in Figure 5–1. No generator will have all the mod-
ules shown. Specifically the Multi–Probe Control-
ler and the Press Control Modules are mutually
exclusive. The modules are shown here to indi-
cate their installed locations and connector types.
Multi–Probe
Slave U/S
Outputs
Multi–Probe
Master U/S
Outputs
Press Base
Abort
Power Signal
Output Monitor
EEPROM Serial
Programming Port
Remote Amplitude
Control
IEC
AC Power
Input
Ultrasound
Output
System
Input
Multi–Probe
Master U/S
Input
System
Output
Thruster
Operational
Control
Rear AC
Power Switch
Grounding
Lug
(DPC II Plus only) (DPC II Plus only)
(DPC II Plus only)
Figure 5–1 DPC II Plus and EZ Welder Rear Panel Connectors
