46
9 - START UP PROCEDURE
P07
00..02 = No function is associated
03 = This is an input contact for CH request (e.g. trigger phone).
When contact CN2 is closed and Room Thermostat (RT) requiring heat switches burner on.
Note: verify heating mode is enabled (winter or heat only mode)
04 = This is an input contact for Low Temperature Thermostat (e.g. oor heating system).
When Low Temperature Thermostat connected on CN2 cuts out, burner switches off and display shows
E178 anomaly.
Note: verify heating mode is enabled (winter or heat only mode)
05 = This is an input contact for external DHW recirculation pump. When contact CN2 is closed the pump
runs for a specic period.
To enable input it is necessary to set parameter P04 or P05 = 08 and P69 = 05.
Pump will run at P19 minutes (Summer/Winter mode or Only Winter mode) or P19/2 minutes (only
Summer mode).
00
P09
Manufacturer information
--
P10
Heating setpoint setting OT / RT (Open Therm / Room Thermostat 120V~)
00 = with Remote Control (RC) connected, temperature request is RC setpoint
01 = Temperature Request is highest set point between RC and PCB
02 = Temperature request is RU setpoint. The RT enable the gas boiler operates
00
P11..P12
Manufacturer information
--
P13
Max. heating output (0-100%)
100 80
P14
DHW max. output (0-100%)
100
P15
Min. heating output (0-100%)
00
P16
Maximum CH setpoint (°C)
00 = 176°F (80°C)
01 = 113°F (45°C)
00
P17
Pump overrun time in heating mode (01-240 minutes)
03
P18
Burner ignition delay in CH mode (00-10 minutes) - 00=10 seconds
03
P19
Manufacturer information
07
P20
Pump overrun time in DHW mode (seconds)
30
P21
Anti-legionellosis function
00 = Disabled -
01 = Enabled
00
P22
Manufacturer information
(set “22” to display parameters P71 and P72)
00
P23
Maximum DHW setpoint temperature 113°-140°F (45°-60°C), Default 49 = 120°F
49
P24
Manufacturer information
35
P25
No water safety device
00
P26..P31
Manufacturer information
--
P32..P41
Diagnostics (See SERVICE Instructions)
--
P44
Temperature unit setting
00 = °C
01 = °F
01
P71 * P
Maximum fan speed
--
P72 *
Minimum fan speed
--
* See Tables : SECTION 12.2 - Parameters Setting For High Altitude.
NOTE : To scroll to parameter P71 and P72 it is necessary to set P22 to 22 before scrolling up to the parameter.
P06
Outdoor temperature sensor input conguration
00= with outdoor temperature sensor connected, external temperature value has inuence to calculate
heating ow temperature setpoint
01= with outdoor temperature sensor connected, display shows external temperature value (no inuence)
02…05 = no function is associated
00
9.14 Description Of Parameters: Factory Settings conti.
FACTORY SETTINGS
125-165 150-205
