1-5
Chapter 1 Before Operation
No. Name Function
[1] Top cover Cover for ensuring user safety. This machine will not operate if
open.
[2] Control panel Use this panel to enter information to operate the machine.
(p.1-11)
[3] Folding misalignment adjustment Adjusts folding misalignment.
(p.2-17)
[4] Inlet for stacker connector Insert the connector of the belt stacker to this inlet.
[5] Stopper cover Open the cover when a paper jam occurs. This machine will not
operate if open.
(p.5-4)
[6] Manual feed guide F/B Move these guides according to a paper size when feeding paper
manually.
(p.3-15)
[7] Power switch
”1. Turning On/Off the Power” (p.2-1)
[8] Manual feed inlet/paper feed inlet When using this machine alone, insert paper into this inlet
manually.
(p.3-15)
When connected to a upstream unit, paper from the upstream unit
is conveyed through this inlet.
[9] Main power switch
”1. Turning On/Off the Power” (p.2-1)
[10] Power inlet Inlet for the power cord
To Next Page
