Duplo DBM-150 User Manual

3-10
Chapter 3 Advanced Operation
5
Attach the side guides F and B (L).
1) Align the axes of the knob screws of the
side guide F (L) with the notches of the
DBM-150.
2) Insert the front edge of the side guide F (L)
under the guide of the DBM-150.
3) Align the corner of the side guide F (L) with
that of the bracket for the side guide as
shown in the gure.
4) Secure the knob screws (2 each).
5) Attach the side guide B (L) in the same way.

Duplo DBM-150 Specifications

General

Brand	Duplo
Model	DBM-150
Category	Trimmer
Language	English
