6-2
Chapter 6 Appendix
Model DBM-150 DBM-150T
Maximum processing
speed
2,400 sets/hour (ne quality 81.4 g/m² /22 lb 10 sheets or fewer with saddle stapling and
folding A5 nished)
When using the SXS MODIFICATION KIT (option), 1,720 sets/hour (using ne quality paper
81.4 g/m² /22 lb A4 SEF/LT SEF 2 sheets)
Detecting function Paper jam (infeed section, stapling section, stopper section, ejecting section)
Cover open/close
Knife stop position error
Motor overload detection
Airborne noise Equivalent continuous A-weighted sound pressure level (* L
Aeq
): 75.2 dB
Sound pressure level peak (L
pC
): 92.5 dB
Measured at 1.5 m/59 inches above the oor, 1 m/39.37 inches away from the control
panel
Noise test EN13023 J.3.1.1 - Grade 3
* L
Aeq
is the value added consideration of the variation with time to the A-weighted sound
pressure level L
pA
.
Power supply 120 to 240 V 50/60 Hz
Power consumption and
current consumption
230 W (Excl. DBM-150T 130 W), 2.2 to 1.1 A (Excl. DBM-150T 1.2 to 0.7 A)
Dimensions When used
DBM-150: 1,010 (W) x 560 (D) x 710 (H) mm/39.76 (W) x 22.05 (D) x 27.95 (H) inches
including the belt stacker
DBM-150+DBM-150T: 1,421 (W) x 560 (D) x 710 (H) mm/55.94 (W) x 22.05 (D) x 27.95 (H)
inches including the belt stacker
Required space
DBM-150: 1,112 (W) x 670 (D) x 989 (H) mm/43.78 (W) x 26.38 (D) x 38.94 (H) inches
including the belt stacker
DBM-150+DBM-150T: 1,522 (W) x 670 (D) x 1,087 (H) mm/59.92 (W) x 26.38 (D) x 42.80 (H)
inches including the belt stacker
Weight (Mass) DBM-150: 85 kg/187.2 Ib. including the belt
stacker and accessories
DBM-150T: 49 kg/107.9 Ib. including the
accessories
(*1)Depending on the combination of paper, specications may be limited. Ask your dealer for details.
Options for the DBM-150
Model Name of product
CORNER AND SIDE STAPLE KIT KIT
SXS MODIFICATION KIT KIT
