18
6. Using the DC-6 mini, DC-8 mini
2 Take out a sheet of paper on the feed bin and feed it out
along the straight stacking guide up to the paper
receiver tray.
3 Set the jogger (left) to a position with a space of about
5mm from the paper.
10 Attach the feed lever to the above
position.
11 Press the preset key.
• Sheets of paper consisting of a set are fed from the
bins and the number of bins and fed sheets is displayed
on the counter display window.
Refer to “Preset key” on page 20.
• The feed bin error lamp blinks when the paper is not
stacked in the bin or when the paper is not fed from the
bin.
Check the a set of sheets discharged on the
paper receiver tray.
Jogger(left)
Paper
Straight
Stacking
Guide
FeedLever
5mm
