5-
2
Chapter 5 Cleaning the Machine
P
aper feed ring
Clean with a cloth moistened with alcohol
rotating the paper f
eed ring by hand.
F
olding roller
1
Remov
e the folding plat
e 1.
2
Clean with a cloth moistened with
alcohol rota
ting the jam corr
ection
knob
.
2.
C
lean
in
g
the
L
CD
L
CD display
Wipe the L
CD on the control panel with the dry cloth.
91
93
