37
5.10 STOP COATING and ACTIVATE CLEANING
5.10.1 Press button to stop coating operation. The fault indicator will
flashing, once the light is stop means cooling down is complete.
5.10.2 Switch the pumping valve from UV to Cleaning
5.10.3 Slid the circulation pan to cleaning funnel.
5.10.4 Press button to perform cleaning, fault indicator blinking.
5.10.5 Press button to stop cleaning, the fault indicator will stop.
Note: Cleaning job will take 3 minutes for Gloss varnishing, other varnishing
may need a bit longer time.
UV Valve
Cleaning
Valve
UV Oil
Funnel
Cleaning
Funnel
