Placing the toothed belt at the bottom

16 Service Instructions 171/173 - 00.0 - 01/2020

5 Placing the toothed belt at the bottom

Fig. 3: Placing the toothed belt at the bottom

To place the toothed belt at the bottom:

1. Place the toothed belt.

Make sure both screws in slot C assume the position shown above

and can be accessed with a screw driver ( p. 13).

CAUTION

Risk of injury from moving parts!

Crushing possible.

Switch off the machine before you adjust the

adjusting disk.
