5. Knives for corner incision
Caution: Danger of injury !
Do not reach into the area of the corner knives.
The corner knives shooting up can cause severe cuts.
Carry out adjusting operations with utmost caution when the sewing
unit is running.
5.1 Presetting
In order to be able to precisely adjust the position of the corner
knives 1 all four corner knives are at first brought in a basic position.
–
Loosen screws 6.
–
Turn the corner knife holders 2 in such a way that the front sides 3
are positioned face to face.
–
Tighten screws 6.
–
Adjust the other two knife holders a s described.
3
61
6
5
1
2
3
4
