1.1 Gauges
The gauges listed below allow a precise setting and testing of the
sewing unit.
The locking peg 1 belongs to the s tandard accessories of the sewing
unit. It serves to stake out the position A (looping stroke).
The setting gauges marked with *) are available on inquiry.
Position Setting gauge Order No. Use
1 Locking peg 0211 000700 Looping stroke position
2 *) Gauge 0246 002591 Crank pin to arm shaft
3 *) Gauge 0244 001001 Height of hook shaft
4 *) Measuring bridge 0212 004942 Height of needle holder
5 *) Measuring pin 0216 001070 Height of needle holder
6 *) Adjusting pin 0244 001014 Lateral hook distance
4
