11.6 Swivelling the stacker aside
For adjusting the corner knives the stacker can be swivelled aside.
–
Loosen the pawl 1.
–
Swivel the stacker aside.
–
Let the stacker catch in its position again after the adjusting
operations.
–
With the screw 2 the stacker can be set close to the stand.
12. Exchange the control unit
See:
Part 2, Installing Instructions: “Sewing software installation” and
Part 4, Instructions for programming: Chapter 3.5 “Dongle Menu”.
3
81
2
1
