7.7.4 Edit the machine parameters
Via t he machine parameters the basic machine settings and some of
the parameters for all programs are defined.
–
Click Edit -> Machine parameters.
MP1 - Configuration
Needle cooling
The following modes can be set:
without
The needle cooler is not activated.
Air cooling (def.)
During sewing the needle is cooled with air.
Ice cooling
Optional equipment.
Sewing foot mode
The sewing foot can be operated in the following modes:
Jumping foot
The sewing foot presses onto the material while the
needle penetrates the material.
Presser foot
The sewing foot presses continuously onto
the material.
Sewing area size
Sewing area normal size (def.)
A sewing field of 200*300 mm is available.
Sewing area oversize
In connection with the change-over clamp a
larger sewing field can be used.
36
