Optional equipment
Reduced clamp pressure
Optional equipment that facilitates the alignment
by exercising a reduced clamp pressure at the
feeding moment.
Laser marking lamp
Optional equipment that facilitates the alignment
at feeding by providing orientation lines.
Here this option is only enabled and then with
each program up to four laser marking lamps can
be activated.
Bar code reader
Optional equipment for a security check before
the sewing process. With each program a barcode
can be deposited. It will be cross-checked with
the barcode on the clamp.
Only if the codes are identical the sewing process
will be started.
Clamp type
The following kinds of clamps are available:
One-piece clamp for L-shape adaptation
Single-piece parallel clamp with angular feed
One-piece clamp for with bow (def.)
Single-piece parallel clamp with bow feed
Split clamp for L-shape adaptation
Tw o-piece parallel clamp with angular feed
Exchangeable clamp
Removable clamp
Special clamp
Individual clamp
Clamp limitation
Preset limitation (def.)
No additional structures are taken into account.
Special limitation
Individual limits are taken into account.
Set Pedal mode
The following modes are available:
Mode 1
The recent position of the pedal is evaluated.
Mode 2 (def.)
The pedal has to be pushed back into the initial
position after each actuation before a further
actuation is taken into account.
Mode 3
The recent position of the pedal is evaluated.
Additionally the quick start mode is enabled (see
the program parameter feeding mode). The recent
position of the pedal is evaluated.
Additionally the quick start mode is enabled (see
the program parameter feeding mode)
In order to activate the quick start mode, the machine
must be switched off and on again!
Hand switch
In the hand switch mode one sensor is used only for
the operation of the clamp movement (up and down).
The other sensor serves to start the sewing process.
