Te st the output elements
With this test function the functioning of the output
elements will be tested.
Caution: Risk of injury!
Do not reach into the running machine during the function test
of the output elements.
–
Press the button “output elements”.
–
Press “selected”.
–
Enter the desired output element and select it.
Output number Signification
Y1 Sewing foot mode:
Y2 Open the bobbin case latch
Y3 Needle cooler on
Y4 Clamp right side
Y5 Clamp left side
Y9 Lamp thread in button on
Y10 War ning light oil level on
Y25 Laser marking lamp 1 (Z)
Y26 Laser marking lamp 2 (Z)
Y27 Laser marking lamp 3 (Z)
Y28 Laser marking lamp 4 (Z)
