Error code Description Remedy
2156 Stepping motor X-axis overheat
- Stepping motor seized up
- Faulty stepping motor
- Control faulty
- Eliminate seizing
- Replace stepping motor
- Replace the control
2201 Stepping motor Y-axis time out referencing
- Setting reference switch faulty
- Faulty cable to the reference switch
- Faulty reference switch
- Al ig n t he re fe re nc e s wi t ch
- Replace the cable
- Replace the reference switch
2202 Stepping motor Y-axis faulty current supply
- Stepping motor blocked
- Encoder cable disconnected/faulty
- Encoder faulty
- Remove the blocking
- Check/replace the encoder
cable
- Replace the encoder
2252 Stepping motor Y-axis excess current
- Replace the stepping motor
- Replace the control
2253 Stepping motor Y-axis excess voltage
- Mains voltage too high
Check the mains voltage
2255 Stepping motor Y-axis overload
- Feeding system rough-running
- Obstacles at feeding movements
- Remove the blocking
- Remove the obstacles/
Adapt the movements
2256 Stepping motor Y-axis overheat
- Feeding system blocked
- Faulty stepping motor
- Control faulty
- Eliminate seizing
- Replace stepping motor
- Replace the control
2301 Stepping motor stroke position time out
ref ere n ci n g
- Setting reference switch faulty
- Faulty cable to the reference switch
- Faulty reference switch
- Al ig n t he re fe re nc e s wi t ch
- Replace the cable
- Replace the reference switch
2302 Stepping motor stroke position faulty current
supply
- Stepping motor blocked
- Encoder cable disconnected/faulty
- Encoder faulty
- Remove the blocking
- Check/replace the encoder
cable
2352 Stepping motor stroke position excess current
- Replace the stepping motor
- Replace the control
2353 Stepping motor stroke position excess voltage
- Mains voltage too high
Check the mains voltage
2355 Stepping motor stroke position overload
- Feeding system rough-running
- Obstacles at feeding movements
- Remove the blocking
- Remove the obstacles/
Adapt the movements
2356 Stepping motor stroke position overheat
- Feeding system blocked
- Faulty stepping motor
- Control faulty
- Eliminate seizing
- Replace stepping motor
- Replace the control
Control/Machine
3100 Machine control voltage
Te mporary mains voltage drop
Check the mains voltage
3102 Machine voltage intermediate circuit sewing motor
Te mporary mains voltage drop
Check the mains voltage
3103 Machine voltage intermediate circuit stepping
motors
Te mporary mains voltage drop
Check the mains voltage
