Dymax BlueWave® 200 Version 3.0 User Guide
Specifications
System Specifications
Property
Specification
Part Numbers
41015
41014
41013
North American Version (with 115V standard plug)
Asian Version (with type G plug)
BlueWave 200 with no power cord*
Intensities
Total
(280-450)
40+ W/cm
2
Visible
(400-450 nm)
17+ W/cm
2
UVA**
(320-395 nm)
17+ W/cm
2
UVB
(280-320 nm)
7 W/cm
2
Power Requirements
100 to 240 VAC, 50 to 60 Hz, 2.5 Amps
Power Supply
Solid State, 200 Watt
Bulb
200 Watt mercury Bulb included; replacement in less than a minute
Reflector
Elliptical; glass with diachronic coating to reflect UV and minimize IR
Shutter Timer
0-9999 seconds, 0.1 seconds resolution
Shutter Activation
Foot Pedal, Front Panel Key Press, or PLC
I/O Port
15-Pin D – sub-miniature connector
Signals (PLC Integration)
Inputs
Shutter activate, shutter deactivate, lamp control, PLC enable
Outputs
Unit status, temperature fault, shutter fault, lamp status, power status,
shutter status, lightguide status, bulb life warning, bulb life expired
Cooling
Filtered, single fan arrangement; thermally controlled to maintain proper lamp temperature
Operating Conditions
Temperature range: 0 – 40°C humidity limit – non-condensing
Display
LCD, monochromatic, 320 by 240 pixels
Housing Dimensions,
W x D x H
12.5" x 12.0" x 6.5" (31.8 cm x 30.5 cm x 16.5 cm)
Weight
12.75 lbs. (5.78 kg)
BlueWave® 200 Warranty
1 year from purchase
Bulb Warranty
2,000 hours (no intensity warranty during 2,000 hours, only lighting)
Replacement Bulb
38465
* For European customers, the appropriate power cord will be added. Systems shipped without a power cord shall not use power cord rated less than
10A/120 VAC or 6A/230VAC in accordance with IEC 60320.
** Measured with an EIT Spotcure Radiometer or an ACCU-CAL™ 50 Radiometer using a lightguide simulator and standard internal “Cool Blue” Filter.
