Maintenance Manual (960-948) 4-31
Replacement Procedures
2. Remove the following screws.
Figure 4-33 Removing the keyboard (2)
3. Remove the KEYBOARD.
Figure 4-34 Removing the keyboard (3)
S1.2×1.1BT
KEYBOARD
