dynabook Portege X30L-K Series - System board

Maintenance Manual (960-948) 1-7
Hardware Overview
Table 1-3 M.2 SSD specifications (Micron)
1.3 Keyboard
The computer’s keyboard layouts are compatible with a 104/105-key
enhanced keyboard - by pressing some keys in combination, all of the
104/105-key enhanced keyboard functions can be performed on the
computer.
Figure 1-3 is a view of the keyboard. See Appendix D about the layout of
the keyboard.
Figure 1-3 Keyboard
1.4 Display
The display consists of 13.3-inch FHD LCD module.
Width (mm) 22.00 ± 0.15 22.00 ± 0.15
Height mm) 2.38 Max 2.38 Max
Depth (mm) 80.0 ± 0.15 80.0 ± 0.15
Weight (g) 9.0 Max 9.0 Max
Storage size
(formatted)
512GB 1TB
Items Specifications
G8BC000CU510 G8BC000CU1A0
Width (mm) 22.00 ± 0.15 22.00 ± 0.15
Height mm) 2.3 Max 2.3 Max
Depth (mm) 80.0 ± 0.15 80.0 ± 0.15
Weight (g) 10.0 Max 10.0 Max
Storage size
(formatted)
512GB 1TB
Items Specifications
