Dynacord PM 502 User Manual

Table of contents
1
Safety 4
2
Quick overview 7
2.1 Shipping contents and warranty 7
3
System overview 8
4
Installation 9
5
Connection 10
5.1 Mains input 10
5.2 Audio inputs 10
5.2.1 Mono inputs (MIC/LINE) 10
5.2.2 Stereo inputs 11
5.3 Audio outputs 12
5.3.1 Speaker connection 12
5.3.2 Line level/USB 14
5.3.3 Headphone 15
5.4 Other connections 15
5.4.1 USB data storage 15
5.4.2 FX switch 15
6
Configuration 16
6.1 Phantom power 16
6.2 100 V Direct Drive 16
6.3 Amplifier routing 16
6.4 Speaker processing (LPN) 17
6.5 AUX mode 17
6.6 Locking 18
6.7 Microphone processing (TALK OVER) 19
7
Operation 20
7.1 Mono input 20
7.2 Stereo input 22
7.3 FX 23
7.4 AUX 24
7.5 MASTER 24
7.6 Microphone processing 24
7.7 Equalizer 25
7.8 Display 26
7.8.1 Menu 26
7.9 Indicators 30
7.10 Headphone volume 31
8
Maintenance 32
9
Technical data 33
9.1 Dimensions 37
9.2 Circuit diagram 38
10
Appendices 39
10.1 System examples 39
10.2 Pin assignments 43
PM 502 Table of Contents | en 3
Bosch Sicherheitssysteme GmbH User manual 15-May-14 | 02 | F01U297804

Dynacord PM 502 Specifications

General

Type	Stand mixer
Product color	Black
DJ mixer	-
USB port	Yes
Rack capacity	7U
Video capability	No
USB connector type	USB Type-B
Sample rate	48 kHz
Amplifier class	D
Frequency range	15 - 22000 Hz
Channels quantity	8 channels
Amplifier output power	1200 W
Supported sample rates	32, 44.1, 48 kHz
Digital sound processing	48 bit
Audio A/D Converter (ADC)	16-bit, delta-sigma
Equalizer bands quantity	7
Master (XLR) out	1
Line inputs (RCA)	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Number of microphone inputs	5
Phantom power	48 V
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	180 W

Weight and Dimensions

Depth	241 mm
Width	395 mm
Height	244 mm
Weight	4900 g
Package weight	6400 g
