Dynacord PM 502 User Manual

Quick overview
Your PM 502 is designed so that you can easily set it up and start using it right away. Follow
the steps on the next few pages to set up your PM 502.
!
Caution!
Read all the instructions in this document and the safety notes starting on page 4 before you
plug your PM 502 into a power outlet.
Shipping contents and warranty
Quantity Component
1 PM 502
1 Power cord
1 User manual
1 Important safety instructions
Warranty
For information regarding the warranty, see www.dynacord.com
2
2.1
PM 502 Quick overview | en 7
Bosch Sicherheitssysteme GmbH User manual 15-May-14 | 02 | F01U297804

Dynacord PM 502 Specifications

General

Type	Stand mixer
Product color	Black
DJ mixer	-
USB port	Yes
Rack capacity	7U
Video capability	No
USB connector type	USB Type-B
Sample rate	48 kHz
Amplifier class	D
Frequency range	15 - 22000 Hz
Channels quantity	8 channels
Amplifier output power	1200 W
Supported sample rates	32, 44.1, 48 kHz
Digital sound processing	48 bit
Audio A/D Converter (ADC)	16-bit, delta-sigma
Equalizer bands quantity	7
Master (XLR) out	1
Line inputs (RCA)	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Number of microphone inputs	5
Phantom power	48 V
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	180 W

Weight and Dimensions

Depth	241 mm
Width	395 mm
Height	244 mm
Weight	4900 g
Package weight	6400 g
