Technical data
Channels (mono + stereo) 5 + 3
Microphone inputs 5 x XLR/Jack socket
Auxiliaries (FX, AUX) 1 Post, 1 Pre
Max. single channel output power, dynamic headroom, IHF-A
• into 4 Ω 640 W
• into 8 Ω 350 W
Max. dual channel output power, dynamic headroom, IHF-A
• into 4 Ω 2 x 600 W
• into 8 Ω 2 x 340 W
Max. single channel output power, continuous, 1 kHz, THD = 1%
• into 4 Ω 500 W
• into 8 Ω 280 W
Max. midband output power, 1 kHz, THD = 1%, dual channel
• into 4 Ω 2 x 450 W
• into 8 Ω 2 x 270 W
Rated output power, 20-20000 Hz, THD < 0.5%, one channel loaded
• into 4 Ω 400 W
• into 8 Ω 240 W
Max. output power, Direct Drive mode (bridge configuration), continuous, 1 kHz, THD = 1%
• into 12 Ω 680 W
Max. output voltage, power amplifier, 1 kHz, no load
• Dual channel mode 52 V
rms
• Direct Drive mode 100 V
rms
THD, at 1 kHz, MBW = 22 kHz
• MIC input to master A L/R outputs, +10
dBu, typical
< 0.015%
• MIC input to speaker output < 0.15%
DIM 30, MIC input to speaker output, 3.15
kHz, 15 kHz
< 0.05%
IMD-SMPTE, MIC input to speaker outputs, 60
Hz, 7 kHz
< 0.15%
Frequency response, -3 dB, ref. 1 kHz
• Any input to any Mixer output 15–22000 Hz
9
